Features:
- Fully Mac OS X supported with with on-screen
menu set-up and CD-ROM with user guide, quick
installation guide, and user manual
documentation.
- 32-bit interface fits standard internal PCI card slot
- IEEE 802.11n draft 2.0 compliant
- Up To 4x greater range with MIMO technology
- Up to 300Mbps data transmission rate
- Backward compatible with 802.11g/b
- Moveable antenna base
- Designed to stream movies, music, photos,
HD video, VoIP phone calls, and large files
- Advanced security features: 64/128bit WEP,
WPA, WPA2
- 2 year warranty
- Register Here
|
Specifications:
- Standards: IEEE draft 802.11n, 802.11b/g
- Chipset: Ralink RT2860 (MAC/BBP )
and RT2820 (RF)
- LEDs: Activity
- Data Rate:
11b: 11, 5.5, 2, 1 Mbps per channel
11g: 54, 48, 36, 24, 18, 12, 9, 6Mbps per channel
11n (20MHz): 144, 130, 115, 86, 57, 43, 28, 14Mbps
11n (40MHz): 270, 240, 180, 120, 90, 60, 30Mbps
- Output Power:
11g: 14.5dBm@54Mbps
11b: 17.5dBm@11Mbps
11n (20MHz): 12.5dBm@144Mbps
11n (40MHz): 12.5dBm@270Mbps
- Frequency Band: 2.4000~2.4835GHz
(Industrial Scientific Medical Band)
- Dimensions: 4.92" x 4.72" x 0.79"
(125 x 120 x 20mm)
- Weight: 2.65 ounces
- Certifications: FCC, CE
- Temperature Operating: 32ºF to 131ºF
- Temperature Storage: -4ºF to 176ºF
- Humidity: 90%, (non-condensing)
- FCC ID: UNH-MXP802NPCI
|
