NewerTech® : Video : USB 3.0 to DVI/HDMI/VGA to Video Display Adapter

USB to DVI/HDMI/VGA to Video Display Adapter

Video Display Adapter
View more. Create more.
Video Display Adapter
– Add an additional monitor with ease via USB 3.0!
– Increase productivity as much as 50% with an extra monitor.
– Small, lightweight and bus-powered with no AC adapter needed.
– Up to 2048 x 1152 resolution.
DVI, HDMI and VGA Connectivity
USB 3.0 interface
Mac and PC compatible
1 Year NewerTech Product
Limited Warranty
Expand your horizons
Expand Your Horizons...
  • Multitasking
    Multitask more effectively without overlapping windows.
  • Presentations
    Use a laptop to run multiple screens during a large audience presentation.
  • Photoshop
    Design on one screen and use second display for Photoshop pallets/tools.
  • Spreadsheets
    View large spreadsheets across two screens with display continuity.
  • TV/movies
    View Internet TV or DVD movies on one screen and your desktop on the other screen.
  • Charts/Data
    View investment charts and live market data at the same time.
  • e-mails
    Open attachments on one screen while reading the e-mail on the other.
  • Reference
    Type documents on one screen while viewing reference material on the other.
  • Workflow
    Create/produce in one monitor and access files, Internet, e-mail, and FTP in the other.
Video Display Adapter

USB 3.0 to DVI/HDMI/VGA Video Display Adapter

View more. Create more.
Expand your workstation's visual real estate with the NewerTech USB 3.0 to DVI Video Adapter, the easiest way to connect multiple DVI, HDMI, and VGA displays, projectors, and HD televisions to your Mac or PC through your USB 3.0 or 2.0 port.

Boost your productivity levels via this incredibly small, lightweight, bus-powered adapter. Multi-task without overlapping files and application windows for a more efficient workflow, or surf the internet and watch movies in up to 1080p while continuing to access your desktop. View investment charts and live market data simultaneously. Utilize one display for program tools and another for graphics and video production with supported resolutions up to 2048x1152.

Mirror the content on your original screen across any display connected via USB 3.0 or USB 2.0 for dynamic presentations, family videos, photo collections, and more. The built-in dedicated USB bus-powered video card contains the latest chipset and compression technologies for uncompromised full-screen playback of high-definition video, as well as fluid web page and document scrolling.

View more and create more with the multiple display access provided by the NewerTech USB 3.0 to DVI Video Adapter.
  • NewerTech USB 3.0 to DVI Video Adapter
  • USB 3.0 cable (Standard-A to Micro-B)
  • DVI to HDMI adapter
  • DVI to VGA adapter
  • User guide
Power
  • Bus-powered
  • Environmental (Operating)
    • Temperature (°F) 32° — 104°
    • Temperature (°C) 0° — 40°
  • Environmental (Non-Operating)
    • Temperature (°F) -4° — 158°
    • Temperature (°C) -20 — 70°
Dimensions
  • Height: 0.8 in (1.9 cm)
  • Width: 1.8 in (4.6 cm)
  • Length: 2.9 in (7.4 cm)
Warranty
Interface
  • (1) USB 3.0
Video Interface Support
  • DVI
  • HDMI (via included adapter)
  • VGA (via included adapter)
Display Mode Support
  • Extended Desktop (default)
  • Mirrored Desktop
  • Primary Display
Resolution and Color5,6
  • Resolution Support
    • 640x480, 800x600, 1024x768, 1280x720, 1280x768, 1280x800, 1280x1024, 1366x768, 1400x1050, 1600x1200, 1680x1050, 1920x1080, 1920x1200, 2048x1152
  • Color Depth7
    • Support for both 16-bit and 32-bit color quality
System Requirements
  • OS
    • Mac OS X 10.6 - OS X 10.11.6
    • macOS 10.12 - 10.13.31
    • Windows XP SP2 (32-bit)2 or Windows Vista (32-bit or 64-bit) or later
  • Driver
  • Hardware3,4
    • Minimum
      • Mac or PC featuring USB 2.0 interface
    • Recommended (best performance)
      • Mac or PC featuring USB 3.0 interface
  • Notes
    • Video streaming is supported up to 1080p
    • Resume from hibernation and sleep supported
    • Supports up to 4 (Mac) or 6 (PC) USB display adapters simultaneously
  1. To maintain compatibility, at this time we do not recommend using this device with any version of the Mac operating system beyond 10.13.3
  2. Windows XP 64-bit is not supported.
  3. OpenGL hardware acceleration is not supported under OS X or Windows XP, and is not supported in full screen mode under later generations of Windows. Certain application features that require hardware-based OpenGL acceleration will have limited or no functionality.
  4. Varying degrees of support exist for DirectX and Direct 3D technologies in Windows. For more information please visit http://www.displaylink.com/support/ticket.php?id=259
  5. Interlaced and reduced blanking modes are not supported.
  6. Not all displays will support all resolutions and color depth.
  7. Color management workflows are not supported.
  • Download and install the driver software
  • Plug the NewerTech USB 3.0 to HDMI / DVI video display adapter into any of the computer's available USB 3.0 Ports
  • Plug the additional monitor into the video display adapter
